Data Processor Milk Collection Unit (DPU)

Download Pdf

Introducing RTPL's DPUV5: A high-speed 64-bit Armcore microcontroller unit with advanced surface mount technology. Compact and powerful, it optimizes milk collection processes with precision and efficiency.

PRODUCT SPECIFICATIONS

  • Brand: RTPL
  • Model: DPUV5
  • Processor: 64 bit Ultra high speed Armcore Microcontroller
  • Electronics: In housed developed Single board Electronics
  • Technology: Latest Surface Mount Technology
  • Power supply: 12V DC / 3A
  • Peak Power: 50W
  • Operating Environment: 5 To 55 °C
  • Net Weight: 3.0 Kg
  • Physical Dimension (mm): 290( L ) X 245(W ) X 160(H)

TECHNICAL SPECIFICATION

  • Display: 20x4 Jumbo LCD (Blue-White) with Back light
  • Keypad: 5x4 Matrix keypad for user's friendly operation
  • Printer: Thermal Printer - 2.0" Panel Mounted
  • RS-232 Input ports:
  • 1. Milk analyzer
  • 2. External Weighing scale
  • RS-232 Output ports:
  • 1. Remote customer display
  • 2. 2G/3G/4G Modem
  • USB Ports:
  • 1. USB Keyboard interface
  • 2. USB Keyboard interface

Functional Specification

  • Data Storage: 1000 Customers per shift
  • Weighing Scale: Auto Tare, Ltr. conversion and Adjustable Decimal Point Auto configurable Baud Rate
  • Milk Collection Type: Code base OR Fat limit base
  • Cumulative Total: Cumulative Total in slip , 10 Days / 15 Days / Monthly
  • Protection: Password Protection at various stages
  • Data & Reports: CSV format Export to Pen drive
